SSCycle swingarms for Harley Davidson and SSCyle frames
Our swingarms are build with special founded castings and seamless and cold-drawn high quality steel tubes. All parts are welded with MIG and TIG welding process. Because of this high quality materials the swingarms are more stable than the originals. All swingarms come with a German TÜV Certification according to the newest European standard and with a serial no.
Swingarm for SSCycle 'Twin Cam' frames
These swingarms are specialy
made for our Twin Cam frame but you can use it in "orig/standard" design as a
swingarms for the original frames too.
They allow you to install wheels with a maximum width of 240mm. The XL swingarm
belongs to the XL frame and offers you to use wheels even with a maximum width
of 280mm.
| Order no. | Description |
|---|---|
| 96-10240 | Swingarm for SSC Twin Cam frame, orig./standard |
| 96-10242 | Swingarm for SSC Twin Cam frame, XL |
| 96-10246 | Offset Swingarm for SSC Twin Cam frame, orig./standard |
| 96-10248 | Offset Swingarm for SSC Twin Cam™ frame, XL |
Swingarm for SSCycle 'Custom-Style' frames
The standard type of this
swingarm can be used with the original Softail frame too.
The XL and XXL typ belongs to the appropriate XL or XXL frame and gives you the
possibility to use wheels up to a maximum width of 240mm. That's not enough? -
Then choose an "Offset" swingarm where you can install wheels up to a maximum
width of 280mm.
| Order no. | Description |
|---|---|
| 96-10150 | Swingarm for Custom-Style frame, org./standard |
| 96-10160 | Swingarm for Custom-Style frame, XL |
| 96-10170 | Swingarm for Custom-Style frame, XXL |
| 96-10220 | Offset-Swingarm for Custom-Style frame, orig./std. |
| 96-10222 | Offset-Swingarm for Custom-Style frame, XL |
| 96-10224 | Offset-Swingarm for Custom-Style frame, XXL |
Our "Drag-Style" swingarm
let your bike look like a Dragster. As standard for the original Softail or our
Custom-Style frame for wheels up to 240mm width or as XL/XXL for our
Custom-Style frame with max. wheel-width of 240/280mm.| Order no. | Description |
|---|---|
| 96-10230 | Drag-Style Swingarm, original/std. |
| 96-10232 | Drag-Style Swingarm, XL |
| 96-10234 | Drag-Style Swingarm, XXL |
Swingarm for SSCycle 'Softass' frames
These swingarms have the same technical advantages as the "Custom Style" swingarms but they look like the tail of the original Harley Davidson® rigid frame which was build up to 1957
| Order no. | Description |
|---|---|
| 96-10110 | Swingarm for Softass frame, orginal/std. |
| 96-10120 | Swingarm for Softass frame, XL |
| 96-10130 | Swingarm for Softass frame, XXL |
| 96-10210 | Offset-Swingarm for Softass frame, original/std. |
| 96-10212 | Offset-Swingarm for Softass frame, XL |
| 96-10214 | Offset-Swingarm for Softass frame, XXL |
Swingarm for SSCycle 'Early-style' frame and OEM FX/FL frame
These swingarms are made for our 'Early-style' frame but fits as well to the original HD swingarm frame up to 1984. Made of steel or aluminium in standard or Drag-Style design available. The standard type takes wheels up to 200mm width. The XL/XXL type (made of steel only) belongs to the appropriate XL/XXL frame and takes wheels up to 240mm
SSCycle std. Swingarm
| Order no. | Description |
|---|---|
| 96-03500 | SSC-Aluminim Swingarm, polished, FX/FL '58-'84, compl. |
| 96-03501 | SSC-Aluminim Swingarm, raw, FX/FL 58-84, compl. |
| 96-03600 | SSC Swingarm FX/FL 56-84 for disc brake, compl. |
| 96-03605 | SSC Swingarm FX/FL 56-84 for hydraulic drum brake, compl. |
SSCycle Drag-Style swingarm
| Order no. | Description |
|---|---|
| 96-03502 | SSC Drag-Style Aluminim Swingarm, polished ,FX/FL58-84, compl. |
| 96-03503 | SSC Drag-Style Aluminim Swingarm, raw, FX/FL58-84, compl. |
| 96-03002 | SSC Drag-Style Swingarm FX/FL 56-84 for disc brake, compl. |
SSCycle aluminium excentric swingarm
This swingarm with excentric adjusters fits for all Harley Big-Twin swingarm
models up to 1984.
It can take tires up to 200mm width and is 50mm longer as the original one.
Because of the variable fixation for the shocks it is possible to lower the bike
as you want. A milled slot at the inside of the right arm can keep idividual
anchors.
This swingarm is welded of high quality aluminium profile-tube and comes
complete with axle, bearings, fixations for the shocks, excentric wrench and
German TÜV Certification.
| Bestell Nr. | Description |
|---|---|
| 96-03500 | SSC-Aluminim Swingarm, polished, , compl. |
| 96-03501 | SSC-Aluminim Swingarm, raw, , compl. |
